Digger Plant Trailer - 3.2m x 1.7m, 3.5t, 2 Axle, 12in wheel - Brian James

Brian James Trailers

Digger Plant Trailer - 3.2m x 1.7m, 3.5t, 2 Axle, 12in wheel - Brian James

£5,478.00 inc VAT

£4,565.00 exc VAT
Sale Sold out
Load Restraint
Ramp Style

Shipping & Returns

Shipping: We offer the same day dispatch if ordered before 2pm. Usual delivery times are 1 - 3 days.

Returns: Please contact us via telephone or email, we will then arrange a collection via courier.

For more information and additional specs, Call Alex: 07584169303

The innovative Digger Plant range provides a modern, advanced and compliant transport solution for many tracked excavators and plant machines such as chippers and shredders. With obvious appeal to larger organisations, the ideas pioneered in the Digger Plant also translate to smaller fleets and individual users interested in efficiency and safety.

Standard Features

Digger Plant has a gross capacity of 3,500kg. It combines this with class leading light, but tough chassis design to achieve unrivalled payload capability. Whether moving diggers or dumpers our advanced low chassis design and versatile layout, achieves recommended weight distribution, ensuring stable and safe towing.

The deck design is constructed using heavy duty phenol ply (18mm), with substantial under deck chassis reinforcements. Even the heaviest machinery such as road rollers or mini diggers will not cause damage. Robust steel mudguards and all around high-grip side steps provide easy and safe access to machinery on the trailer.

Loading ramp

Equipped as standard with a singular punched loading ramp, HD hinge with nylon brush and featuring a HD ramp clamp mechanism, the ramps are fully adjustable to fit any machine size. With the ability to change the ramp type, allowing you to conquer all loading challenges with our one-piece ramp solution. Its spring lift assistance and knife edge panels effortlessly transport goods up to a generous height, while a mesh infill ensures easy loading of all vehicles.



Multiple anchor points

Numerous strap attachment points are located in the chassis providing ultimate strength. A high level of grip and strength is offered by the raised, punched profile of each slot. Machine restraint is made easy with many tie-down options.

Super-structure

The strength of Digger Plant is more than skin deep. Super-strength steel used in the main chassis fabrication is complemented by two additional longitudinal beams just below the 18mm phenol ply anti-slip centre bed. Lighter weight and improved strength, combined with the durability of a hot-dip galvanised chassis ensures that Digger Plant will serve for many years.

TracStrap system

The Tracstrap system is unique to Brian James Trailers and the Digger Plant. This in-house designed and manufactured system offers extremely high levels of towing security with minimal effort (TÜV Nord test report 8114838799). The front chocks are adjustable and provide a fixed loading point. Each track is held in place by a 5 tonne rated 50mm wide straps featuring heavy duty wear protectors.

Lead Time:

Solid Punched Ramp - In-Stock

Mesh Infill Loading Ramp: 4-5 weeks

Standard Loading Ramps: 4-5 weeks

Applicability

Specifications

Description
